A real job, real heatmaps.

The house on the home page is a model. This one is a real home, shared with the owner kept anonymous. More case studies go up as clients say yes.

Networks & Wi-Fi · Nocatee area

Whole-home Wi-Fi in a single-story home

One router in the front corner left the back bedrooms in the red. Two access points, placed on the floor plan first, covered the house.

Read the case study
Before: Wi-Fi heatmap of the Nocatee-area home, from the original single router in the front corner. Green near the router fades to yellow and red across the back bedrooms and baths.
Before
After: three-dimensional heatmap of the Nocatee-area home with both access points. Nearly every room is green, with small yellow edges in a few corners.
After

From the job

Racks, access points and the work in between

  • An open structured-media enclosure in a wall: UniFi switches, a firewall and a patch panel mounted on a white backplate, with blue patch cables and printed labels such as “top switch”, “poe switch” and “firewall”.
    A structured-media enclosure: switches, firewall and patch panel, each one labeled.
  • UniFi equipment set out on its boxes with status lights on: a round access point, a wall-plate access point, a gateway and a switch, cabled with short white patch cords.
    UniFi gear set up and lit, staged before it goes in.
  • A white UniFi access point mounted flush on the textured ceiling of a home gym, its blue status ring lit, above a red power rack with a black pull-up bar and wall mirrors.
    A ceiling-mounted UniFi access point covering a home gym.
  • A small black network rack with a glass door and two numbered patch panels, next to two ceiling access points and a switch on the carpet, and a coil of black patch cables in front.
    A rack going together: patch panels in, access points and switch staged beside it.
  • The back of a network rack: bundles of white network cables tied together with black cable ties, running past rack-mounted equipment.
    Behind the rack: runs bundled and tied off.
  • An open alarm panel enclosure: the control board with its wiring terminals at the top and a 12-volt backup battery below.
    An alarm panel and its backup battery.

What you get

Wi-Fi projects come with paperwork you can use

  • A floor plan

    Rooms, walls and where the internet comes in.

  • Before and after heatmaps

    Where the signal was weak, and where it is now.

  • Notes on what’s where

    Equipment, cables and settings, written down.

Want the model version, where you flip between a typical setup and mine? Step inside the house

Your home could be the next case study

Only if you want it to be. Either way, it starts with a free 15-minute call.
